Description

InfiRay RICO MICRO RH25 V2 — Multifunction Thermal Monocular

The RH25 V2 is InfiRay’s second-generation RICO MICRO — a 640×480 thermal with magnesium alloy housing that functions as a handheld scanner, helmet-mounted monocular, standalone weapon sight, or thermal clip-on in front of a day optic. 60Hz refresh, ≤15mK NETD, 1,375 yard detection, 18650 battery (~6.5 hrs), USB-C external power, 64GB onboard recording with audio.

---

Key Features

Four modes in one unit

Handheld scanner, helmet mount (via AC52 Pictail with dovetail interface), standalone weapon sight, or clip-on thermal in front of LPVOs, prism sights, and holographic sights with magnifier (up to 6×).

640×480 sensor, 12µm, ≤15mK NETD

InfiRay Micro II sensor with MATRIX III processing. 60Hz refresh rate for smooth tracking. 1,375 yard detection range.

1440×1080 AMOLED display

80% larger physical viewing area than V1, 97% more pixels. Extended eye relief eyepiece with clip-on compatibility up to 6×.

18650 battery + USB-C external power

~6.5 hours per 18650 battery (2 included). USB-C port for indefinite runtime via external pack. Also supports file transfer via USB-C.

64GB onboard recording

Video and audio recording. Recoil-activated recording. Up to 1,600 images / 40 hours of video. Wi-Fi and Bluetooth for app control and file transfer.

Recoil and weatherproof

Rated to 7mm/.300 WM recoil. IP67 waterproof. Machined magnesium alloy housing.

---

Specs at a Glance

Sensor	640×480, 12µm, InfiRay Micro II
NETD	≤15mK
Lens	25mm f/1.0 Germanium, manual focus
Magnification	1× to 4× digital zoom
Detection range	1,375 yards
Refresh rate	60Hz
Display	1440×1080 AMOLED
Weight	~11.3 oz
Housing	Machined magnesium alloy
Battery	18650 (~6.5 hrs); USB-C external power
Storage	64GB internal
Connectivity	Wi-Fi, Bluetooth, USB-C
Waterproof	IP67
Recoil rated	Up to 7mm/.300 WM

Common Questions

Can this thermal imager be used with night vision?
Thermal imagers work independently of ambient light and do not require an image intensifier tube. They can be used alongside night vision as a separate device, or as a standalone tool in complete darkness, smoke, or heavy vegetation.

What is the detection range on this unit?
Detection range varies by model, target size, and ambient conditions. For specific range performance on this unit, call us at (888) 330-7057 or review the spec sheet linked in the product description.

Is this export controlled?
Yes. Thermal imaging devices are subject to U.S. export control regulations under ITAR and EAR. For sale to U.S. persons only. By purchasing you acknowledge compliance with applicable export control laws.
